Understanding U0073: More Than a Glitch
When your OBD-II scanner flashes U0073—Control Module Communication Bus “A” Off, it signals a critical network failure. This generic diagnostic trouble code (DTC) means your vehicle’s high-speed CAN bus (500 kbps–1 Mbps) has shut down. This bus links vital modules:
-
Powertrain control (throttle, turbo, fuel injection)
-
Transmission control (TCM)
-
Safety systems (ABS, ESC, steering)
-
Comfort modules (climate, navigation)
Ignoring U0073 risks emergency limp mode, sudden stalling, or complete system shutdowns while driving.
Symptoms: How U0073 Manifests
Watch for these red flags:
-
Instrument cluster failure: Frozen speedometer/tachometer or “dashes” instead of readings.
-
Warning lights: Check Engine + ESP/ABS lights stay on.
-
Performance drops: Transmission locks in emergency gear, engine revs capped at ~2,500 RPM.
-
Random electrical faults: Headlights, windows, or AC turning off unexpectedly.
Note: Symptoms may vanish after restarting—but the problem isn’t gone. Intermittent failures worsen over time.
Top Causes of U0073 (Ranked by Frequency)
|
Cause
|
Description
|
|
CAN Wiring Damage (40-50%)
|
Corrosion in underbody connectors (e.g., near door sills) or frayed wires from vibration/rubbing. Common in Toyota Camry/Corolla (battery tray harness) and Chevy Cruze (cracked engine harness seals)
|
|
Short Circuits (20-30%)
|
CAN-High/CAN-Low wires touching each other or power/ground. Check aftermarket alarm/tracker installations.
|
|
Terminal Resistor Failure (15%)
|
Damaged 120Ω resistors at bus ends. Resistance tests should show ~60Ω (parallel pair). Readings of 120Ω (open) or ∞ (short) confirm faults.
|
|
ECU Failures (10-15%)
|
“Silent” modules (e.g., TCM, ECM) dragging down the network. Prevalent in Ford Focus (BCM leaks) and BMW F30 (vibration-damaged DME connectors).
|
Diagnosing U0073 Like a Pro
Tools you’ll need:
-
An advanced scan tool (like CR Eagle) for active/pending codes and live CAN data.
-
Multimeter (min. 1 MS/s sampling) or oscilloscope.
-
Breakout pins for connector testing.
Step-by-Step:
-
Full system scan
Identify all U0073-related codes (e.g., U0100, U0140).
-
Reset codes
Restart the engine. Note which codes return first—pinpoint the “culprit” module.
-
CAN signal check
Probe CAN-High (typically 2.5–3.5V) and CAN-Low (1.5–2.5V). Flatlined voltage = dead bus.
-
Resistance test
Unplug the battery. Measure resistance between CAN-High/Low pins. ~60Ω = normal; 120Ω = broken resistor; ∞ = short.
-
Divide-and-conquer
Disconnect half the CAN modules. If signals normalize, the fault is in the disconnected section.
Fixes: From Quick Resets to Major Repairs
DIY Checks (10 minutes):
-
Disconnect the battery for 5 minutes to reset all ECUs.
-
Remove aftermarket devices (trackers, audio systems) tapped into CAN wires.
-
Inspect wiring harnesses near door sills, battery trays, and ECMs.
Advanced Repairs:
-
Repair wiring: Splice damaged CAN lines with twisted/shielded replacements. Seal connectors with dielectric grease.
-
Replace terminators: Faulty 120Ω resistors cause network instability.
-
Update firmware: Reflash affected modules using dealer-grade tools.
-
Swap faulty ECUs: Test by substituting suspected modules (e.g., TCM, gateway).
For recurring U0073 after rain or bumps, focus on corroded sills/connectors or loose harnesses.
Why CR Eagle is Your U0073 Diagnostic Partner
Pinpointing CAN bus faults requires real-time data streaming and module-specific access. CR Eagle delivers:
CAN Bus Monitoring
Trace signal drops across all ECUs to identify failing modules
Live Voltage Graphs
Spot intermittent shorts during test drives with high-resolution tracking
Coding Capabilities
Reset terminators or reflash modules post-repair to restore network integrity
Module Communication Tests
Isolate unresponsive ECUs causing bus shutdowns
Case Study: A 2015 Ford Focus with U0073 + U0140 showed erratic BCM signals. CR Eagle traced it to a corroded footwell connector—fixed in 20 minutes.
Critical FAQs
Q: Can I drive with U0073?
A: No. Sudden power loss or brake/steering failure is possible, posing significant safety risks.
Q: Does an aftermarket alarm cause U0073?
A: Yes—60% of non-factory devices disrupt CAN signals, especially poorly installed units tapping into network wires.
Q: Why does U0073 vanish temporarily?
A: Vibration/temperature changes can temporarily restore connections, hiding faults until electrical loads increase (e.g., using AC or headlights).
Q: How much does it cost to fix U0073?
A: Costs range from $50 (DIY wiring repair) to $500+ (ECU replacement). Aftermarket device removal is often low-cost but effective.
Final Advice
U0073 is a network emergency. Start with battery/connector checks, then escalate to CAN tests with tools like CR Eagle. For model-specific fixes (e.g., VW Golf gateway issues or Chevy Malibu harness cracks), consult your repair manual.
Catch CAN bus faults early—before they strand you.
